The function of the multi-inputs can only be configured in the PC utility software.
Two alarm levels are available for each input, the menu numbers of the alarm settings for each multi-input are
controlled by the configured input type as seen in the following table.
Input type Multi-input 102 Multi-input 105 Multi-input 108
4 to 20 mA 4120/4130 4250/4260 4380/4390
0 to 40 V DC 4140/4150 4270/4280 4400/4410
Pt100/Pt1000 4160/4170 4290/4300 4420/4430
RMI oil 4180/4190 4310/4320 4440/4450
RMI water 4200/4210 4330/4340 4460/4470
RMI fuel 4220/4230 4350/4360 4480/4490
Digital 3400 3410 3420
Only one alarm level is available for the digital input type.
4.6.1 4 to 20 mA
If one of the multi-inputs has been configured as 4 to 20 mA, the unit and range of the measured value corre-
sponding to 4 to 20 mA can be changed in the PC utility software in order to get the correct reading in the
display.
4.6.2 0 to 40 V DC
The 0 to 40 V DC input has primarily been designed to handle the battery asymmetry test.
4.6.3 Pt100/1000
This input type can be used for heat sensor, for example cooling water temp. The unit of the measured value
can be changed from Celsius to Fahrenheit in the PC utility software in order to get the desired reading in the
display.
4.6.4 RMI inputs
The unit can contain up to three RMI inputs. The inputs have different functions, as the hardware design al-
lows for several RMI types.
These various types of RMI inputs are available for all multi-inputs:
RMI oil: Oil pressure
RMI water: Cooling water temperature
RMI fuel: Fuel level sensor
For each type of RMI input it is possible to select between different characteristics including a configurable.
4.6.5 RMI oil
This RMI input is used to measure the lubricating oil pressure.
