Deif GPC-3 Designers Reference Handbook

RMI sensor
type
Temperature Type 1 Type 2 Type 3 Type 4
°C °F Ω Ω Ω Ω
40 104 291.5 480.7 69.3
Type 4 is not available when RMI
water is selected
50 122 197.3 323.6
60 140 134.0 222.5 36.0
70 158 97.1 157.1
80 176 70.1 113.2 19.8
90 194 51.2 83.2
100 212 38.5 62.4 11.7
110 230 29.1 47.6
120 248 22.4 36.8 7.4
130 266 28.9
140 284 22.8
150 302 18.2
The configurable type is configurable with eight points in the range 0 to 480 Ω. The tempera-
ture as well as the resistance can be adjusted.
If the RMI input is used as a level switch, then be aware that voltage must not be connected to
the input. If any voltage is applied to the RMI input, it will be damaged. Refer to the Application
Notes for further wiring information.
4.6.7 RMI fuel
This RMI input is used for the fuel level sensor.
RMI sensor type
Type 1
Value Resistance
0 % 78.8 Ω
100 % 1.6 Ω
RMI sensor type
Type 2
Value Resistance
0 % 3 Ω
100 % 180 Ω
If the RMI input is used as a level switch, then be aware that voltage must not be connected to
the input. If any voltage is applied to the RMI input, it will be damaged. Refer to the Application
Notes for further wiring information.
GPC-3 DRH 4189340587 UK Additional functions
DEIF A/S Page 45 of 122
