RMI sensor type
Pressure Type 1 Type 2 Type 3
Bar psi Ω Ω Ω
0 0 10.0 10.0
Type 3 is not available when RMI
oil is selected
0.5 7 27.2
1.0 15 44.9 31.3
1.5 22 62.9
2.0 29 81.0 51.5
2.5 36 99.2
3.0 44 117.1 71.0
3.5 51 134.7
4.0 58 151.9 89.6
4.5 65 168.3
5.0 73 184.0 107.3
6.0 87 124.3
7.0 102 140.4
8.0 116 155.7
9.0 131 170.2
10.0 145 184.0
The configurable type is configurable with eight points in the range 0 to 480 Ω. The resistance
as well as the pressure can be adjusted.
If the RMI input is used as a level switch, then be aware that voltage must not be connected to
the input. If any voltage is applied to the RMI input, it will be damaged. Refer to the Application
Notes for further wiring information.
4.6.6 RMI water
This RMI input is used to measure the cooling water temperature.
GPC-3 DRH 4189340587 UK Additional functions
DEIF A/S Page 44 of 122
