Deif GPC-3 Designers Reference Handbook

AOP
M-Logic is used when the AOP is used for switching between the four sets of nominal settings. Select the
required AOP push-button among the input events, and select the nominal settings in the outputs.
Example:
Event A Event B Event C Output
Button07 or Not used or Not used Set nom. parameter settings 1
Button08 or Not used or Not used Set nom. parameter settings 2
See the “Help” file in the PC utility software for details.
Menu settings
In menu 6006, the switching is made between settings 1 to 4 simply by choosing the desired nominal setting.
Busbar
Two sets of nominal settings are available for the busbar (menus 6050 and 6060). Switching between the
busbar nominal settings can only be done through M-Logic. For details, refer to the previous description
about how to handle the generator nominal settings.
If required, the phase angle between the generator and busbar can be adjusted if a transformer is installed
between generator and busbar. The adjustment is done in menu 9141 for busbar nominal settings 1 and in
menu 9142 for busbar nominal settings 2.
4.18 Relay setup
The GPC-3 has several relay outputs available. Each of these relays can be given a special function depend-
ing on the required functionality. This is done in the I/O setup (menu 5000-5270).
GPC-3 DRH 4189340587 UK Additional functions
DEIF A/S Page 74 of 122

Deif GPC-3 Specifications

General

Model	GPC-3
Protection front	IP65
Power consumption	10 W
Operating temperature	-20°C to +55°C
Storage temperature	-40°C to 85°C
Communication	Ethernet
Display	Graphical LCD
Dimensions	144 x 144 x 115 mm
