2V 4V 6V 8V 10V-10V -8V -6V -4V -2V
-1Hz
-2Hz
-3Hz
-4Hz
-5Hz
5Hz
4Hz
3Hz
2Hz
1Hz
Parameter Name Setting
2843 Max. f/P 8 V
2844 Min. f/P -6 V
Parameters 2843 “Max. f/P” and 2844 “Min. f/P” are shared between fixed frequency and fixed
power because they both use the same analogue input.
Fixed var
The scaling of the analogue input is done in parameters 2845 “Max. U/Q” and 286 “Min. U/Q”. There is no
scaling of var range, it will always be from 0 to 100 % of the nominal power set point.
