Menu Default Name Description
2616 0.1[%/s] Ramp up speed 2 Slope of ramp 2 when
ramping up.
2623 0.1[%/s] Ramp down speed 2 Slope of ramp 2 when
ramping down (not used
for de-load).
2624 ON Auto ramp selection Activate or deactivate
automatic selection of
secondary ramps.
The frequency-dependent droop is only available in fixed power mode.
This function relates to settings 7051 and 7121-7143.
All configurable relays can be chosen to be a horn output. This means that the relay can be connected to an
alarm annunciator, for example a horn. Every time a new alarm occurs, the horn output will activate.
The horn output will activate on all alarms. The output remains activated until:
● The alarm is acknowledged
● The horn relay timer runs out (automatic reset function)
When a relay is used as a horn relay, it cannot be used for other purposes.
The horn output will not activate on limit switch functions.
Automatic reset
The horn relay function has an automatic reset function. When the timer (menu 6130) differs from 0 seconds,
the horn relay output resets itself when the delay has expired. This is also the situation when the alarm is
STILL present.
The horn output resets when the alarm is still present. This is the function of the “Automatic
reset”.
Manual reset
If the time is set to 0.0 s, the automatic reset of the horn output is disabled. The horn will remain ON until the
alarm is acknowledged by the operator. Now, the status of the alarm changes from unacknowledged (UN-
ACK.) to acknowledged (ACK.).
If the alarm condition is gone when the alarm is acknowledged, then the specific alarm mes-
sage also disappears.
The controller has two transistor outputs, each representing a value for the power production. The outputs are
pulse outputs, and the pulse length for each of the activations is 1 second.
GPC-3 DRH 4189340587 UK
Additional functions
DEIF A/S Page 62 of 122
