EX3000 iDRAC cabling

Provides wiring diagrams for the iDRAC cables that connect the iDRAC port on the node to the

Fox back-end switch for the EX3000S system (single node chassis configuration) and the

EX3000D system (dual node chassis configuration).

The EX3000S node iDRAC port to the Fox switch (BE1) port connections are listed in the following

table.

Table 31 EX3000S node iDRAC port to BE1 port mapping

Node 1 iDRAC port BE1 Port 17

Node 2 iDRAC port BE1 Port 18

Node 3 iDRAC port BE1 Port 19

Node 4 iDRAC port BE1 Port 20

Node 5 iDRAC port BE1 Port 21

Node 6 iDRAC port BE1 Port 22

Node 7 iDRAC port BE1 Port 23

Node 8 iDRAC port BE1 Port 24

EX3000 Platform

ECS EXSeries Hardware Guide 111
