EX3000 upgrade paths
Describes the EX3000 ECS appliance upgrade paths.
You can add EX3000S nodes in one-node increments to an existing system. The nodes must match
the existing drive configuration. For example, if your system contains EX3000S nodes with 90 disk
drives you can only add EX3000S nodes configured with 90 disk drives.
You can add EX3000D nodes in two-node increments to add to an existing system. The nodes
must match the existing drive configuration. For example, if your system contains EX3000D nodes
with 30 disk drives you can only add EX3000D nodes configured with 30 disk drives (60 drives per
chassis).
You can add drives to partially populated EX3000 nodes. The following drive upgrades are
supported:
l
Convert EX3000S-45 to EX3000S-60
l
Convert EX3000S-60 to EX3000S-90
l
Convert EX3000D-30 to EX3000D-45
EX3000 server
The EX3000 4U server contains the EX3000 chassis and either one server sled (in the EX3000S
single node configuration) or two server sleds (in the EX3000D dual node configuration). EX3000
servers have the following standard features:
l
One-node or two-node servers (4U) with two CPUs per node
l
Dual 8-core Broadwell CPU per node. E5-2620v4 8-core/16-thread 2.1GHz 20M cache 85W
l
4x16GB RDIMM, 2400MT/s, Dual Rank, x8 Data Width
l
One system disk per node (480 GB SSD)
l
LED indicators for each node
l
Dual hot-swap chassis power supplies per node
l
One SAS adapter with two SAS ports per node
The EX3000 physical dimensions are listed in the following table.
Table 26
EX3000 physical dimensions
Height 173.8 mm (6.84 inch)
Width with rack latches 482.4 mm (18.99 inch)
Width without rack latches 448.0 mm (17.64 inch)
Depth 1,098.4 mm (43.24 inch)
Total depth of system with cable management
(CMA) arm attached
1,242.68 mm (48.92 inch)
Weight (maximum) 134.0 kg (295.42 lb)
Weight (empty) 57.1 kg (125.88 lb)
