The EX500 appliance connections to 0U PDU and 2U PDU outlets are listed in the following tables.
The table describes EX500 0U PDU single-phase zone A/B mapping.
Table 10 EX500 0U PDU single-phase zone A/B mapping
PDU outlet Branch Component Line cord per zone
37 12 Empty 3
36 12 Empty 3
35 12 Empty 3
34 12 Empty 3
33 11 Node 16 3
32 11 Node 15 3
31 11 Node 14 3
30 10 Empty 2
29 10 Empty 2
28 10 Empty 2
27 9 Empty 2
26 9 Empty 2
25 9 Node 13 2
24 8 Node 12 2
23 8 Node 11 2
22 8 Node 10 2
21 7 Node 9 2
20 7 Node 8 2
19 7 Node 7 2
18 6 Empty 1
17 6 Empty 1
16 6 Empty 1
15 5 Empty 1
14 5 Empty 1
13 5 Empty 1
12 4 FE Switch 2 1
11 4 FE Switch 1 1
10 4 Tray/Light Bar 1
9 3 BE Switch 2 1
8 3 BE Switch 1 1
7 3 Empty 1
EX500 Platform
ECS EXSeries Hardware Guide 33
