Table 7 EX500 Disk Upgrade Kit
Disk Upgrade Kit Quantity Upgrade Result Per
Server
12-disk upgrade 1 EX500 - 12 to 24 disk
upgrade
EX500 server
Learn about the EX500 servers standard features.
Lists the features of EX500 servers.
Table 8 Standard features of EX500 servers
Features 8 TB 12 TB
Chassis
l
EX500 24 x 3.5" 2 CPU chassis
l
One-node server (2U) with two CPUs per node
l
Maximum chassis weight is 43.2 kg (95.24 lb)
Riser
Configuration
l
Each EX500 server supports up to eight PCI express (PCIe) Gen3
expansion cards that can be installed on the system board using three
expansion card risers.
l
Config 1 (1B + 2B)
l
Four x8 slots and rear storage
Processors 2x Xeon Silver 10 core/20 thread 85W
Memory 8 x 8GB RDIMM, 2666MT/s, Single Rank, x8 Data Width
Disk Controller HBA330 mini (IOC, JBOD)
PCIe Slot 1 Broadcom 57414 2x25GbE, QSFP28
PCIe Slot 2 BOSS controller card + with 1 M.2 stick 480 GB, LP
PCIe Slot 3 Broadcom 57414 2x25GbE, QSFP28
Management iDRAC9 Enterprise
Power 2 x 1100W Platinum
HDDs in front
slots
8TB 7.2k RPM 512e SATA HDD 12TB 7.2k RPM 512e
SATA HDD
Figure 8 EX500 server physical dimensions
EX500 Platform
ECS EXSeries Hardware Guide 27
