The EX300 appliance connections to 0U PDU and 2U PDU outlets are listed in the following tables.
Table 20 EX300 0U PDU cabling
PDU cabling PS1 outlet
numbers
PS2 outlet
numbers
Line cord per zone (Single
phase)
Zone B Zone A
Black cables Gray cables
Node 16 21 21 2
Node 15 20 20 2
Node 14 19 19 2
Node 13 18 18 1
Node 12 17 17 1
Node 11 16 16 1
Node 10 15 15 1
Node 9 14 14 1
Node 8 13 13 1
FE 2 12 12 1
FE 1 11 11 1
Service Tray and
Light Bar
10 10 1
BE 2 9 9 1
BE 1 8 8 1
Node 7 7 7 1
Node 6 6 6 1
Node 5 5 5 1
Node 4 4 4 1
Node 3 3 3 1
Node 2 2 2 1
Node 1 1 1 1
Table 21 EX300 2U PDU cabling
2U PDU cabling PS1 outlet
numbers
PS2 outlet
numbers
Line cord per zone (Single
phase)
Zone B Zone A
Black cables Gray cables
Node 16 21 21 3
Node 15 12 12 3
EX300 Platform
ECS EXSeries Hardware Guide 67
