Table 21 EX300 2U PDU cabling (continued)
2U PDU cabling PS1 outlet
numbers
PS2 outlet
numbers
Line cord per zone (Single
phase)
Zone B Zone A
Black cables Gray cables
Node 14 11 11 3
Node 13 10 10 3
Node 12 9 9 3
Node 11 20 20 2
Node 10 19 19 2
Node 9 18 18 2
Node 8 17 17 2
FE 2 13 13 1
FE 1 1 1 1
Service Tray and
Light Bar
8 8 2
BE 2 14 14 1
BE 1 2 2 1
Node 7 7 7 2
Node 6 6 6 2
Node 5 5 5 2
Node 4 16 16 1
Node 3 15 15 1
Node 2 4 4 1
Node 1 3 3 1
In the following diagrams, the switches plug into the front of the rack and route through the rails
to the rear.
EX300 Platform
68 ECS EXSeries Hardware Guide
