Table 12 EX500 2U PDU single-phase zone A/B mapping (continued)
PDU outlet Branch Component Line cord per zone
7 2 Node 7 2
6 2 Node 6 2
5 2 Node 5 2
4 1 Node 2 1
3 1 Node 1 1
2 1 BE Switch 2 1
1 1 BE Switch 1 1
The table describes EX500 2U PDU three-phase Delta and Wye zone A/B mapping.
Table 13 EX500 2U PDU three-phase Delta and Wye zone A/B mapping
PDU outlet Branch Component Line cord per zone
24 6 Empty 1
23 6 Empty 1
22 6 Empty 1
21 6 Node 16 1
20 5 Node 11 1
19 5 Node 10 1
18 5 Node 9 1
17 5 Node 8 1
16 4 Node 4 1
15 4 Node 3 1
14 4 FE Switch2 1
13 4 FE Swtich 1 1
12 3 Node 15 1
11 3 Node 14 1
10 3 Node 13 1
9 3 Node 12 1
8 2 Tray/Light Bar 1
7 2 Node 7 1
6 2 Node 6 1
5 2 Node 5 1
4 1 Node 2 1
3 1 Node 1 1
2 1 BE Switch 2 1
