Table 27 Server indicators, buttons, or connectors (continued)
Item Indicator, Button, or Connector Description
perform a graceful shutdown before power to the system is
turned off.
6 System identification button
l
The identification button can be used to locate a particular
system within a rack.
l
Press to toggle the system ID on and off.
l
If the system stops responding during POST, press and hold the
system ID button for more than five seconds to enter BIOS
progress mode.
l
To reset iDRAC (if not disabled in F2 iDRAC setup) press and
hold the button for more than 15 seconds.
7 Power indicator The power indicator glows when the system is turned on.
8 ID indicator When a system identification button is pressed, the ID indicator
blinks blue to help locate a particular system within a rack.
9 Sled B HDD fault status indicator
l
The indicator blinks amber if an HDD experiences an issue.
l
Note: Features of Sled B are for dual-node systems only.
10 System board status indicator If the system is on, and in good health, the indicator glows solid blue.
The indicator blinks amber if the system is in standby, and if any
issue exists (for example, a failed fan or HDD).
11 Power button
l
The power button controls the PSU output to the system.
l
Note: On ACPI-compliant operating systems (OSs), turning
off the system using the power button causes the system to
perform a graceful shutdown before power to the system is
turned off.
12 System identification button
l
The identification button can be used to locate a particular
system within a rack.
l
Press to toggle the system ID on and off.
l
If the system stops responding during POST, press and hold the
system ID button for more than five seconds to enter BIOS
progress mode.
l
To reset iDRAC (if not disabled in F2 iDRAC setup) press and
hold the button for more than 15 seconds.
EX3000 Platform
ECS EXSeries Hardware Guide 97
