Dell EMC ECS EX Series User Manual

Table 10 EX500 0U PDU single-phase zone A/B mapping (continued)
PDU outlet Branch Component Line cord per zone
6 2 Node 6 1
5 2 Node 5 1
4 2 Node 4 1
3 1 Node 3 1
2 1 Node 2 1
1 1 Node 1 1
The table describes EX500 PDU three-phase Delta and WYE zone A/B mapping.
Table 11 EX500 PDU three-phase Delta and WYE zone A/B mapping
PDU outlet Branch Component Line cord per zone
37 12 Empty 1
36 12 Empty 1
35 12 Empty 1
34 12 Empty 1
33 11 Empty 1
32 11 Empty 1
31 11 Empty 1
30 10 Empty 1
29 10 Empty 1
28 10 Empty 1
27 9 Empty 1
26 9 Empty 1
25 9 Empty 1
24 8 Empty 1
23 8 Empty 1
22 8 Empty 1
21 7 Node 16 1
20 7 Node 15 1
19 7 Node 14 1
18 6 Node 13 1
17 6 Node 12 1
16 6 Node 11 1
15 5 Node 10 1
14 5 Node 9 1
EX500 Platform
34 ECS EXSeries Hardware Guide
