Figure 100. Removing the rear drive cage
Next step
Install the rear drive cage.
Related link
Removing a drive carrier
Installing the rear drive cage
Installing the rear drive cage
Prerequisite
Follow the safety guidelines listed in Safety instructions.
Steps
1 Align the screws on the drive cage with the screw holes on the system chassis.
2 Lower the drive cage into the system until it is rmly seated and the screws locks into place.
3 Using Phillips #2 screwdriver, tighten the screws.
Installing and removing system components
143
