Dell EMC PowerEdge R540 - Thermal Restriction Matrix

Expanded operating temperature Specications
NOTE: Outside the standard operating temperature (10°C to
40°C), the system can operate down to –5°C or up to 45°C for a
maximum of 1% of its annual operating hours.
For temperatures between 40°C and 45°C, de-rate maximum allowable
temperature by 1°C per 125 m above 950 m (1°F per 228 ft).
NOTE: When operating in the expanded temperature range, system performance may be impacted.
NOTE: When operating in the expanded temperature range, ambient temperature warnings may be reported on the bezel's LCD
panel and in the System Event Log.
Expanded operating temperature restrictions
• Do not perform a cold startup below 5°C.
• The operating temperature specied is for a maximum altitude of 3050 m (10,000 ft).
• Redundant power supply conguration is required.
• AEP DIMM is not supported.
• GPGPU card is not supported.
• Rear drive conguration is not supported.
• 12 x 3.5 inch SM conguration with CPU 140 W/130 W/115 W/105 W_4C is not supported.
• LRDIMM is not supported.
• Non-Dell qualied peripheral cards and/or peripheral cards greater than 25 W are not supported.
• Tape backup unit (TBU) is not supported.
Thermal restriction matrix
Table 30. Thermal restriction matrix for
R540
Storage conguration Front 8 drive 12 drive 12 drive
Rear NA NA 2 drive
Fan type Standard fan Standard fan High
performance fan
CPU heat sink type 1.5U heat sink 1.5U heat sink 1U heat sink
Processor
number
TDP (W) Core count Ambient = 35°C Ambient = 35°C Ambient = 30°C Ambient = 30°C
Intel Xenon Gold
6138
125 20
Yes Yes Yes Yes
Intel Xenon Gold
6130
125 16
Yes Yes Yes Yes
Intel Xenon Gold
6126
125 12
Yes Yes Yes Yes
Intel Xenon Gold
6128
115 6
Yes No Yes Yes
Technical specications 33
