3. Press the memory module down until it clicks into place.
NOTE: If you do not hear the click, remove the memory module and reinstall it.
1.
Connect the battery cable.
2. Install the base cover.
3. Follow the procedure in After working inside your computer.
WLAN card
Removing the WLAN card
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
3. Remove the battery.
The figure indicates the location of the WLAN card and provides a visual representation of the removal procedure.
1.
Remove the screw (M2x4) that secures the WLAN card bracket to the WLAN card.
2. Remove the WLAN card bracket from the WLAN card.
3. Disconnect the antenna cables from the WLAN card.
4. Slide and remove the WLAN card from the WLAN card slot.
Installing the WLAN card
If you are replacing a component, remove the existing component before performing the installation procedure.
The figure indicates the location of the WLAN card and provides a visual representation of the installation procedure.
18
Removing and installing components
