Dell PowerEdge XE8640 User Manual

Table 7. PowerEdge system weight handling recommendations
Chassis weight Description
40 pounds - 70 pounds Recommend two person to lift
70 pounds- 120 pounds Recommend three person to lift
≥ 121 pounds Recommend to use a server-lift
Processor specifications
Table 8. PowerEdge XE8640 processor specifications
Supported processor Number of processors supported
4
th
Generation Intel Xeon Scalable processors with up to 56
cores
Two
PSU specifications
The PowerEdge XE8640 system supports up to 4 AC power supply units (PSUs) with 3+1 redundancy, auto-sensing, and
auto-switching capability.
Table 9. PSU specifications
PSU Class Heat
dissipation
(maximum
) (BTU/hr)
Frequency
(Hz)
Voltage AC DC Current (A)
High line
240 VDC
Low line
100–120 V
2800 W
AC
Titaniu
m
10500
BTU/hr 50/60
200 - 240 V
AC
autoranging
2800 W NA NA 15.6 A
2800 W
DC
NA 10500
BTU/hr
NA
240 V DC NA NA NA 13.6 A
Cooling fan specifications
The PowerEdge XE8640 system supports up to six high performance 60 mm fans in the mid fan frame and five high
performance 80 mm fans in the front for GPU cooling.
Each fan is enclosed in a mechanical assembly to make up the module. The fan modules are hot-swappable with one rotor fan
fail. The system should always be populated with the full set of fans to support the airflow requirements of the chassis
For more information about the supported fan configuration or matrix, see Thermal restriction matrix.
22
Technical specifications
