General memory module installation guidelines
To ensure optimal performance of your system, observe the following general guidelines when configuring your system memory.
If your system's memory configuration fails to observe these guidelines, your system might not boot, stop responding during
memory configuration, or operate with reduced memory.
The memory bus may operate at speeds of 4800 MT/s depending on the following factors:
● System profile selected (for example, Performance, Performance Per Watt Optimized (OS), or Custom [can be run at high
speed or lower])
● Maximum supported DIMM speed of the processors
●
Maximum supported speed of the DIMMs
NOTE: MT/s indicates DIMM speed in MegaTransfers per second.
The system supports Flexible Memory Configuration, enabling the system to be configured and run in any valid chipset
architectural configuration. The following are the recommended guidelines for installing memory modules:
● All DIMMs must be DDR5
● If memory modules with different speeds are installed, they operate at the speed of the slowest installed memory module(s).
● Populate memory module sockets only if a processor is installed.
● For dual-processor systems, sockets A1 to A16 and sockets B1 to B16 are available.
● In Optimizer Mode, the DRAM controllers operate independently in the 64-bit mode and provide optimized memory
performance.
Table 59. Memory population rules
Processor Configuration Memory population Memory population
information
Dual processor (Start with
processor1. Processor 1 and
processor 2 population should
match)
Optimizer (Independent
channel) population order
A{1}, B{1}, A{2}, B{2},
A{3},B{3}, A{4}, B{4}, A{5},
B{5},A{6}, B{6}, A{7}, B{7}
A{8},B{8}
Odd amount or DIMMS per
processor is allowed. DIMMs
must be populated identically
per processor
Removing a memory module
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions.
2. Follow the procedure listed in the Before working inside your system.
3. Remove the air shroud .
WARNING:
The memory modules are hot to touch for some time after the system has been powered off. Allow
the memory modules to cool before handling them.
Steps
1. Locate the appropriate memory module socket.
2. To release the memory module from the socket, simultaneously press the ejectors on both ends of the memory module
socket to fully open.
CAUTION:
Handle each memory module only by the card edges, ensuring not to touch the middle of the
memory module or metallic contacts.
3. Lift the memory module away from the system.
Installing and removing system components
83
