Page #16 background imageLoading...
Page #16 background image
Memory specifications
The PowerEdge XR4510c system supports the following memory specifications for optimized operation.
Table 8. Memory specifications
DIMM type DIMM Rank DIMM capacity
Single processor
Minimum system capacity
Maximum system
capacity
RDIMM Dual Rank
16 GB 16 GB 64 GB
32 GB 32 GB 128 GB
64 GB 64 GB 256 GB
LRDIMM Quad Rank 128 GB 128 GB 512 GB
Table 9. Memory module sockets
Memory module sockets Speed
4, 288-pin 3200 MT/s
NOTE: Memory DIMM slots are not hot swappable.
NOTE: The DIMM memory speed is 3200 MT/s. However, the system memory operating speed is up to 2933 MT/s due to
CPU restrictions.
Storage controller specifications
The PowerEdge XR4510c system supports Boot Optimized Storage Subsystem (BOSS-N1): 2 x M.2 SSDs as internal boot.
Drives
The PowerEdge XR4510c system supports up to 4 x M.2 SSDs (M.2 2280 and M.2 22110) installed on M.2 riser module.
Ports and connectors specifications
USB ports specifications
Table 10. PowerEdge XR4510c USB specifications
Front Internal (Optional)
USB port type No. of ports USB port type No. of ports
USB 3.0-compliant port Two Internal USB 3.0-compliant
port
One
Micro-AB USB 2.0-
compliant port for iDRAC
Direct
One
NIC port specifications
The PowerEdge XR4510c system supports up to four Network Interface Controller (NIC) ports embedded on the LAN on
Motherboard (LOM).
16
Technical specifications
