After working inside your system
Prerequisites
Follow the safety guidelines listed in Safety instructions.
Steps
1. Replace the system cover.
2. If applicable, remove the I/O connector cover from the system connectors. Install the sled into the enclosure.
3. Reconnect the peripherals and connect the system to the electrical outlet, and then power on the system.
Recommended tools
You may need any or combination of the following tools to perform the removal and installation procedures:
● Phillips 1 screwdriver
● Phillips 2 screwdriver
● Wrist grounding strap connected to the ground
● ESD mat
You need the following tools to assemble the cables for a DC power supply unit:
● AMP 90871-1 hand-crimping tool or equivalent
● Tyco Electronics 58433-3 or equivalent
● Wire-stripper pliers to remove insulation from size 10 AWG solid or stranded, insulated copper wire
NOTE: Use alpha wire part number 3080 or equivalent (65/30 stranding).
XR4510c sled
Sled installation guidelines
NOTE: Ensure to install a sled blank in all the empty slots. Operating the enclosure without a blank results in overheating.
Removing a sled blank
Prerequisites
Follow the safety guidelines listed in Safety instructions.
Steps
Pull the sled blank to remove it from the enclosure.
48
Installing and removing system components
