Dell PowerEdge XR4510c system
configurations and features
The PowerEdge XR4510c system is a 1U half-width, 1-processor server sled that supports:
● One 3
rd
Generation Intel Xeon D Scalable processor with up to 20 cores
● Four DDR4 DIMM slots
● Up to 4 x M.2 NVMe SSDs
Topics:
• System configurations - front view for PowerEdge XR4510c
• System configurations - rear view for PowerEdge XR4510c
• System configurations - inside view for PowerEdge XR4510c
• NIC indicator codes
• Locating the Express Service Code and Service Tag
• System information label
System configurations - front view for PowerEdge
XR4510c
Figure 1. Front view for PowerEdge XR4510c
Table 1. Features available on the front view
Item Ports, panels, or slots Icon Description
1 Network I/O ports Provides network connectivity
and can also be shared with
iDRAC when iDRAC network
settings is set to shared
mode.
2 Serial port Enables you to connect a
serial device to the system.
3 USB 3.0 port The USB port is 9-pin
and 3.0-compliant. This port
enables you to connect USB
devices to the system.
4 iDRAC9 RJ-45 dedicated port Enables you to remotely
access iDRAC. For more
2
Dell PowerEdge XR4510c system configurations and features 7
