Dell PowerEdge XR4510c User Manual

Thermal restriction matrix
Table 15. XR4000r RAF Configuration Matrix
CPU Type HSK type Fan type
RAF Configurations
Edge 2 (Max
55°C)
Edge 1 (Max
50°C)
ASHRAE A4 (Max
45°C)
Intel® Xeon® D - 2796NT, 20C,120W
Vaper
Chamber
(VC) HSK
Standard
(STD) fan
Yes Yes Yes
Intel® Xeon® D - 2776NT,16C,117W Yes Yes Yes
Intel® Xeon® D - 2753NT,12C,87W Yes Yes Yes
Intel® Xeon® D - 2733NT,8C,80W Yes Yes Yes
Intel® Xeon® D - 2712T,4C,65W Yes Yes Yes
Table 16. XR4000z RAF Configuration Matrix
CPU Type HSK type Fan type
RAF Configurations
Edge 2 (Max
55°C)
Edge 1 (Max
50°C)
ASHRAE A4 (Max
45°C)
Intel® Xeon® D - 2796NT, 20C,120W
Vaper
Chamber
(VC) HSK
Standard
(STD) fan
Yes Yes Yes
Intel® Xeon® D - 2776NT,16C,117W Yes Yes Yes
Intel® Xeon® D - 2753NT,12C,87W Yes Yes Yes
Intel® Xeon® D - 2733NT,8C,80W Yes Yes Yes
Intel® Xeon® D - 2712T,4C,65W Yes Yes Yes
Table 17. M.2 Support Thermal Limitation for XR4000r Chassis (RAF Configurations)
M.2
Type
Riser Module BOSS Module AIC Card
Edge 2
(Max
55°C)
Edge 1
(Max
50°C)
ASHRAE A4
(Max 45°C)
Edge 2
(Max
55°C)
Edge 1
(Max
50°C)
ASHRAE
A4 (Max
45°C)
Edge 2
(Max
55°C)
Edge 1
(Max
50°C)
ASHRAE
A4 (Max
45°C)
Micron
480GB
Yes Yes Yes Yes Yes Yes Yes Yes Yes
Micron
800GB
Yes Yes Yes Yes Yes Yes Yes Yes Yes
Micron
960GB
Yes Yes Yes Yes Yes Yes Yes Yes Yes
Micron
1.92TB
Throttling
Active
Yes Yes No No No Yes Yes Yes
Micron
3.84TB
Throttling
Active
Yes Yes No No No Yes Yes Yes
Hynix
480GB
Yes Yes Yes Yes Yes Yes Yes Yes Yes
Hynix
800GB
Yes Yes Yes Yes Yes Yes Yes Yes Yes
Hynix
960GB
Yes Yes Yes Yes Yes Yes Yes Yes Yes
Hynix
1.92TB
Yes Yes Yes No No No Yes Yes Yes
Hynix
3.84BT
Yes Yes Yes No No No Yes Yes Yes
