Chapter 6 Applied Instructions
6-333
Binary value
Floating-point
num
ber
Binary-coded
decimal value
Floating-point
number
Floating-point
number
BCD
DINT
FDEG
0
0 5
4
Y1.15~Y1.0
45
R45
D21~D20
R1
D0
R0.785398
D11~D10
FATAN
D31~D30
Additional remark:
If the value in S exceeds the range of values which can be represented by the floating-point
numbers, the instruction is not executed, SM0 is ON, and the error code in SR0 is 16#2013.
