進入此頁面會顯示發生過的事件(Error or fault), 最多可顯示最新的30筆事件,
新的事件置於頂部, 按ENT鍵可檢視所有事件的統計資料。
5.3.4 Event Log
圖5-6 : Event Log頁面
共四頁, 記錄變流器工作的歷史最大資料, 包括輸入/出的最大電壓、電流與功率；
散熱片與變流器內部最高溫度。
5.3.5 Operation Data
圖5-7 : Operation Data頁面
Event Log
21. Jun 2010 13:50
1. 15/02/2010 17:02
2. 02/12/2009 09:13
3. 23/11/2009 15:28
4. 03/10/2009 06:02
5. 27/05/2009 05:52
6. 18/02/2009 16:46
AC Freq High
No Grid
HW Fan
Insulation
Insulation
HW DC Injection
Summary
21. Jun 2010 13:50
HW DC Injection
Temperature
HW NTC1 Fail
HW NTC2 Fail
HW NTC3 Fail
HW NTC4 Fail
Event Count
2
1
0
0
0
0
Event Summary – 1/8
1
0
EXIT
ENT
or
Operation Data – 4/4
21. Jun 2010 13:50
Temperature Max. Min.
Inside
Heatsink - R
Heatsink - S
Heatsink - T
(℃)
(℃)
(℃)
(℃)
59
75
74
73
15
15
15
15
Heatsink - U
Heatsink - V
Heatsink - W
(℃)
(℃)
(℃)
75
74
73
15
15
15
Operation Data – 1/4
21. Jun 2010 13:50
Input1
Voltage
Current
Power
Voltage
Current
Power
Input2
Maximum
(Vdc)
(A)
(kW)
(Vdc)
(A)
(kW)
811
853
506.3
810
886
528.3
Operation Data – 2/4
21. Jun 2010 13:50
L1
Voltage
Current
Power
Voltage
Current
Power
Voltage
Current
Power
L2
L3
Maximum
(Vac)
(A)
(kW)
(Vac)
(A)
(kW)
(Vac)
(A)
(kW)
366
1640
345
365
1631
342
360
1645
338
Operation Data – 3/4
21. Jun 2010 13:50
Output
Voltage
Current
Power
Frequency
(Vac)
(A)
(kW)
(Hz)
Maximum
366
1645
1016
50.10
or
ENT
or
ENT
ENT
or
ENT
138
