Make sure the room for system loading and the destination installation site meet
the space requirements described in this section.
The loading site should provide enough space to unpack the entire system and
release the container. See the following dimensions:
• Height of the package: 2210 mm (87 inches)
• Width of the package: 2280 mm (89.8 inches)
• Depth of the package: 1200 mm (47.2 inches)
• Height of the system: 1980 mm (78 inches)
• Width of the system: 2100 mm (82.7 inches)
• Depth of the system: 950 mm (37.4 inches)
3 Transportation & Installation Preparation
3.1 Installation Site Requirements
3.1.1 Site Space
Figure 3-1 : Inverter Space Requirements
- The ambient temperature range of installation site must be less than 60°C.
- Direct solar irradiation may reduce the output power of the central inverter.
NOTE
17
Transportation & Installation Preparation
