There are 19 parameters in Grid Settings page. User can refer to Table 5-2. for the
function of each parameter.
Parameter Description
Vac High Off
Inverter will be disconnected from grid if the phase voltage of AC rises
to this value.
Vac High On
Inverter will be reconnected to grid if the phase voltage of AC drops to
this value.
Vac High Off T
If AC voltage reaches to the value of Vac High Off, inverter will be
disconnected in this time.
Vac Low Off
Inverter will be disconnected from grid if the phase voltage of AC drops
to this value.
Vac Low On
Inverter will be reconnected to grid if the phase voltage of AC rises to
this value.
Vac Low Off T
If AC voltage reaches to the value of Vac Low Off, inverter will be
disconnected in this time.
Vac High Off Slow
The function is same as Vac High Off, but the value must be lower than
former.
Vac High On Slow
The function is same as Vac High On, but the value must be lower than
former.
Vac High Off Slow T
The function is same as Vac High Off T, but the time must be longer
than former.
Vac Low Off Slow
The function is same as Vac Low Off, but the value must be higher than
former.
Vac Low On Slow
The function is same as Vac Low On, but the value must be higher than
former.
Vac Low Off Slow T
The function is same as Vac High Off T, but the time must be longer than
former.
Fac High Off Inverter will be disconnected from grid if AC frequency rises to this value.
Fac High On Inverter will be reconnected to grid if AC frequency drops to this value.
Fac High Off T
If AC frequency reaches to the value of Fac High Off, inverter will be
disconnected in this time.
Fac Low Off Inverter will be disconnected from if AC frequency drops to this value.
Fac Low On Inverter will be reconnected to grid if AC frequency rises to this value.
Fac Low Off T
If AC frequency reaches to the value of Fac Low Off, inverter will be
disconnected in this time.
Fac High Off Slow
The function is same as Fac High Off, but the value must be lower than
former.
Fac High On Slow
The function is same as Fac High On, but the value must be lower than
former.
Fac High Off Slow T
The function is same as Fac High Off T, but the time must be longer than
former.
Table 5-2 : Grid Setting Parameters
