Delta Modulon DPH series - Page 70

4-8
Modulon DPH Series
O/P DRY
CONTACT
P1 P2 P3
P4
P5 P6
1 4
2 3
1 4
2 3
1 4
2 3
1 4
2 3
1 4
2 3
1 4
2 3
DRY F_NO
DRY E_NO
DRY D_NO
DRY C_NO
DRY B_NO
DRY A_NO
COMM_F
COMM_E
COMM_D
COMM_C
COMM_B
COMM_A
10
112
6
8
2
4
9
11
5
7
1
3
+12VS
DRY 6
+12VS
DRY 5
+12VS
DRY 4
+12VS
DRY 3
+12VS
DRY 2
+12VS
DRY 1
P6 (Max. 0.5A/12V)
P5 (Max. 0.5A/12V)
P4 (Max. 0.5A/12V)
P3 (Max. 0.5A/12V)
P2 (Max. 0.5A/12V)
P1 (Max. 0.5A/12V)
UPS
(Figure 4-9: Output Dry Contacts Design)
