OPERATION MANUAL FOR PCS100HV
42
Step 5: after completing the configuration, check whether PCS100HV is “Standby” status, if it is, the upper level controller sends “Power ON” command
to PCS100HV. PCS will output 3 phase sine wave voltage.
Step 6: when PCS100HV enters the “Normal” status, the local load connected to PCS output can be powered.
Power Off PCS
After PCS100HV is working in standalone mode, one can shut down and power off PCS by following steps.
Step 1: all the load is open, and PCS out power will become to 0.
Step 2: the upper level controller sends “Power OFF” command to PCS100HV, PCS100HV will stops running and enters the “Standby” status.
NOTE: In emergency status, one can press the “EPO” button on the front door to shut down PCS.
Step 3: open the front door.
Step 4: turn the AC and DC switches/disconnects in the front of the cabinet to OFF state as shown in Figure 5-2. The PCS powers off and one can do
maintenance to PCS.
