OPERATION MANUAL FOR PCS100HV
63
3: VDE4105-2018
4: AS4777.2B
5: AS4777.2C
6: AS4777.2-2015
31: Delta Default
Others reserved
2
01
06
10C0
0004
8C F5
Freq-Watt function enable(Over
frequency).
4: 2-Point Mode (FCAS)
[M]
3
01
06
10C6
0004
6C F4
Freq-Watt function enable(under
frequency).
4: 2-Point Mode (FCAS)
[M]
4
01
06
10C1-
10C2,
10C7-
10C8
/
/
Curve points configuration.
The value is different based on
different grid code, please refer to
PCS100HV Protocol.
[O]
5
01
06
0624
03E8
C9 F7
[M]
6
01
06
0625
03E8
98 37
[M]
Note: the 2-point mode is only available in grid code AS4777.2A for EVO project.
Table 39 Steps for disabling Freq-Watt function
STEP
CMD
DESCRIPTION
REMARK
Option
ID(PCS)
Function
Register
Value
CRC REF
1
01
06
10C0
0000
8D 36
Disable Freq-Watt function(Over
frequency).
0: Disable.
[M]
2
01
06
10C6
0000
6D 37
Disable Freq-Watt function(Under
frequency).
0: Disable.
[M]
