DANGER
Live components
Danger to life and limb.
Work on the electrical equipment may only be carried out by a qualified electrician or by trained personnel.
1. Disconnect chain hoist from power supply (mains connection switch) and secure against restarting.
Open and disengage the service cover.
2. Remove and open the bag (1) with the control cable.
3. Take the control cable out of the bag.
4. Loosen bayonet lock (2) by turning and remove control cable plug connection.
5. Unscrew electrical equipment cover.
6. Loosen the screw (3) on the control cable lock and remove the lock. Remove the control cable.
Fit the new control cable in reverse order.
It must be ensured that
● the groove of the connector holder matches the swivel lock in the enclosure and
● that the two pins on the enclosure match the bayonet lock.
Fitting the control pendant ⇒ "Connecting the control pendant", Page 42.
Height adjustment of the control pendant ⇒ "Height adjustment of the control pendant", Page 46.
Tightening torques [Nm] DC-Com 1 DC-Com 2 DC-Com 5 DC-Com 10
Electrical equipment cover 9,5
Service cover
5,5 7,5
Control cable lock 11,0
Tab. 68
21480244/181209
