3.2 Model code
E K L D DC-Com 10 - 2000 2/1 H5 V6/1,5 380 - 415 / 50 24/6 200 220 - 480
Voltage range / Voltage
travel drive[V]
Max. flange width of trolley [mm]
Travel speed [m/min]
Frequency [ Hz ]
Voltage range chain hoist [V]
Hoist speed [m/min]
V
2-stage = Main / creep lifting
VS
Stepless = VS at nominal load up to VS
max
in the partial load range
Hook path [m]
Reeving
Load capacity [kg]
Size
3)
DC-Pro 2-stage chain hoist (Demag chain hoist) DC-ProDi 2-stage chain hoist for direct control
DCM-Pro 2-stage Manulift DC-ProFi Variable speed chain hoist for control by
means of an external frequency inverter
DCS-Pro
Variable speed chain hoist
DCMS-Pro
Variable speed Manulift
DCRS-Pro
Rocker switch stepless DC-Com 2-stage chain hoist basic version
D Articulated curve-running trolley
L
Long monorail hoist
K
Low headroom monorail hoist
U
Standard-headroom monorail hoist
11 Trolley size load capacity [kg • 100]
22
34
56
R Push-travel trolley
E
Travel drive
C F 5 Click-Fit (push-travel trolley)
Tab. 5
Not all features of the mounting code can be combined.
3)
The designations of sizes DC 10 and DC 20 have been changed to DC 10 1/1 and DC 10 2/1 since 04/2006.
21480244/181209
17
