DEMAG DC-Com 5 User Manual

8.5.7.2 Buffer design
Buffer variants
Fig. 63
1 Buffers 2 Buffer plate
3 Switch-off spring
DC-Pro DC-Pro - DC-Pro
DC-Com
with operating limit switch
32)
-
DC-Com
without operating limit switch
32)
-
Load side
Chain collector box
side
Load side
Chain collector box
side
Load side
Chain collector box
side
Load side
Chain collector box
side
A B C D E F G H
Tab. 62
32)
Operating limit switch for lifting and lowering (DC-Com 1 - 10 reeving 1/1 optional, DC-Com 10 reeving 2/1 as standard);
92
21480244/181209

DEMAG DC-Com 5 Specifications

General

Type	Electric Chain Hoist
Load Capacity	500 kg
Safe Working Load	500 kg
Control Type	Pendant control
Protection Class	IP55
Chain Falls	1
Frequency	50 Hz
Power Supply	400 V / 50 Hz
Motor	Three-phase motor
Control	24 V low voltage control
Chain Diameter	5 mm
