25
Basic Operation Basic Operation
2 To choose the surround sound mode
Example: Dolby Digital
Press the STANDARD button.
For more information about the surround modes ( page
31, 32).
The volume can be adjusted within the range of –80 to +18
dB, in steps of 0.5 dB. However, when the channel level is
set ( page 39 or 77), if the volume for any channel is set
at +0.5 dB or greater, the volume cannot be adjusted up to
18 dB. (In this case the maximum volume adjustment range
is “18 dB — (Maximum value of channel level)”.)
Also, you may not be able to adjust the volume to the
maximum of 18 dB when internal volume compensation
control is activated due to the combination of the surround
mode and parameters, downmixing from multi-channel
audio signals into two channels, etc.
2 To select the Room EQ function
Press the ROOM EQ button.
For more information about the Room EQ function (
page 28).
Playing the input source
1
Select the input source to be played.
Example: CD
(Main unit) (Remote control unit)
To select the input source when ZONE2/3/REC SELECT,
VIDEO SELECT or TUNING PRESET is selected, press the
SOURCE button on the main unit then operate the FUNCTION
knob.
2
3
Start playback on the selected component.
For operating instructions, refer to the component’s manual.
Adjust the volume.
(Main unit) (Remote control unit)
To Next Page
