Desoutter CVI3 Function User Manual

Appendix - User info codes _02/2017- 30 -
Type of
code
Code
no.
Description Resolution procedure
Info 242 ToolsNet FIFO alarm 1- The ToolsNet result FIFO has reached alarm threshold, the CVINet
connection has been lost
2- Check the CVI3 Ethernet cable
3- Check CVI3 Ethernet conguration
4- Check if ToolsNet is running correctly
Info 244 Accessory disconnected 1- The accessory at the given address has been disconnected from the
eBUS of the CVI3.
2- Check the accessory cable.
Info 245 Wait report ack Acknowledge report with its corresponding input
Info 251 No Pset selected 1- No Pset is selected
2- Select a Pset before start order
Info 254 Drive comm. error 1- Error detected in drive communication
2- Restart the controller
3- If the problem occurs again, contact your Desoutter representative for
support
Info 259 Reset input active 1- "Reset" input is active
2- The Tightening Unit will unlock when input switchs to inactive state.
Info 261 Locked by IPM 1- IPM protocol has locked the controller
2- Check the connection with the IPM gateway
3- Check CVI3 IPM conguration
Info 262 OP connect. lost 1- Open protocol connection has been lost
Info 263 Socket tray conict For this Tightening Unit, do not associate more than one socket
combination to a Pset
Info 264 Too many steps Check that an ePOD3 is connected to the controller to enable more steps
per pset
Info 266 Message: Incoming message received wth dynamic text
Info 269 Pset modied No procedure
Info 270 Time settings 1-Invalid Time setting
2-Check Pset settings with correct time value settings
Info 271 External tool Pset selected 1- Tool is locked because of External tool Pset selection
Info 272 Debug UsrInfo 1- This UsrInfo is for debug. Contact dev team.
Info 310 Id OK : 1- An identier has been received and accepted.
2- The identier is matching an Assembly process start condition
Info 311 Id NOK : 1- An identier has been received
2- The identier does not match any Assembly process start condition
Info 312 Access expired 1- The access rights on the USB key cannot be read
2- Unplug the key and insert it again
3- If the issue is persistent, the access right le is probably corrupt
4- Contact your CVI Key administrator.
Info 313 Access invalid 1- The access rights on the USB key could not be read
2- Try unplugg the key and insert it again
3- If the issue is persistent, the access right le is probably corrupt contact
your CVI Key administrator
Info 314 CVIKey plugged 1- an access key has been plugged
Info 315 CVIKey unplugged 1- an access key has been unplugged
Info 316 Barcode lost no procedure
Info 400 Default Ntwk Cfg 1- Network conguration has been set to default.
Info 401 Ntwk Cfg Error 1- Network conguration failed.
2- Check your settings.
3- If the problem occurs again, contact your Desoutter representative for
support.
Info 500 CVILogix user info Message generated by CVILOGIX program
Info 888 Controller software updated no procedure
Info 889 Device Software Updated Device Software Updated
Info 891 Controller started No procedure
Info 899 Downgrade not allowed 1- The SW downgrade is not allowed for this version
2- Check the CVI3 image version on your USB key
3- If the update is still failling, contact your Desoutter representative
Info 900 SW update failed 1- The SW upgrade failed
2- Do not remove the USB key and try to restart the CVI3
3- If the upgrade is still failing, contact your Desoutter representative
