Desoutter CVI3 Function User Manual

Appendix - User info codes_02/2017 - 33 -
Type of
code
Code
no.
Description Resolution procedure
Error 32 Tool display error 1- Board display malfunction.
2- Contact your Desoutter representative for support.
Error 34 Tool mem. err 1- The tool memory does not work properly.
2- Contact your Desoutter representative for support.
Error 35 Tool memory locked 1- The tool memory is locked to protect old data from rewriting.
2- Connect the tool to E-dock to retrieve old data.
Error 37 Tool trig err. 1- The tool trigger does not work properly.
2- Check and clean the trigger. If the problem occurs again, contact your
Desoutter representative for support.
Error 45 Anormal battery voltage 1- Anormal battery high voltage, check your battery.
2- This error can due to charger malfunction or end of life battery.
Error 47 Battery is too low 1- Battery is too low, check your battery.
2- If the problem occured again, change the battery with a new one.
Error 48 Battery type not allowed 1- Battery type not allowed.
2- Change your battery type or your conguration.
Error 200 Quick stop ! 1- The quick stop has been activated
2- Check the Phoenix connector
Error 213 Drive Connect. Lost 1- Connection with the drive has been lost.
2- Reboot the controller.
3- If the issue remains, contact your Desoutter representative.
Error 216 Current high 1-Max current exceeded.
2-Contact your Desoutter representative for support
Error 217 Drive disabled 1-Drive disabled by external source.
2-Contact your Desoutter representative for support
Error 218 Drive power failure 1- Drive hardware failure.
2- Safety issue: contact your Desoutter representative for support
Error 219 Trig. safety fail. 1- Drive hardware failure.
2- Safety issue. Contact your Desoutter representative for support.
Error 220 Hardware trip 1- Drive hardware failure.
2- Safety issue. Contact your Desoutter representative for support.
Error 221 Drive check err. 1- Drive hardware failure.
2- Safety issue. Contact your Desoutter representative for support.
Error 222 Controller Too Hot 1- Heatsink too warm.
2- Let the controller cool down.
Error 223 Drive init error 1- Software failure.
2- Restart the controller.
3- If the problem occurs again, contact your Desoutter representative for
support.
Error 227 Motor stalled 1- Motor stalled (could be missing phase, wrong motortune or power
electronics failure)
2- Try once again, if the problem occurs again, contact your Desoutter
representative for support.
Error 228 Drive err. 1- Software failure
2- Restart the controller.
3- If the problem occurs again, contact your Desoutter representative for
support
Error 229 Err. ctrl. loop 1- Software failure.
2- Restart the controller.
3- If the problem occurs again, contact your Desoutter representative for
support.
Error 230 DC bus high 1- Max current exceeded. DC-bus voltage high
2- Contact your Desoutter representative for support
Error 231 DC bus too low 1- Power failure. DC-bus voltage low
2- Contact your Desoutter representative for support.
Error 232 Err. ID eldbus 1- The Fieldbus module plugged in the controller cannot be run. It is not an
authorized Desoutter module.
2- Contact your Desoutter representative for more information.
Error 233 CVINET FIFO full 1- The CVINet result FIFO is full, the CVINet connection has been lost
2- Check the CVI3 Ethernet cable
3- Check CVI3 Ethernet conguration
4- Check if CVINet is running correctly
