Technical Specifications
194
Note: The online help provides an overview of the limits
that should be observed when configuring the
OpenCom 100.
– Range 1000 m
a/b ports
for analogue terminals
with pulse or DTMF dialling,
flash duration of 60 to 310 ms
Possible interface cards:
–4 x a/b
–8 x a/b
–2 x S
0
and 6 x a/b
– Supply voltage 40 V ± 10%
– Supply power 1,2 VA
– Feed current 25 mA
– Range 1000 m
V.24 port (COM)
for connection of a PC 1x (optional)
–Range 3 m
Doorstation equipment interface card
for connection of doorstation equip-
ment
1x (optional)
Contact load of actor 1,5 A / 125 V
–Voltage range U
≈
= 5 V ... 30 V
Sensor Switched by low AC voltage
–Voltage range U
~
= 6 V ... 24 V
