S
2M
Connector Module Configuration
68
On the OpenCom 150 the pressure terminal is a 5-pin connector. The addi-
tional terminal is used to connect the shielding of a shielded line. The shielding
has to be stripped as short as possible (approx. 3 mm).
6. If necessary, check to make sure that the NT is fed by its own power supply.
7. Reconnect the OpenCom 130/150 to the power supply.
8. Configure the S
2M
module in the Configurator of the OpenCom 130/150 (refer
to Configuration starting on page 73). Check the level 1 status with reference to
the LEDs on the module. None of the LEDs are illuminated before the S
2M
module has been configured.
9. Pull out the mains plug of the OpenCom 130/150 again and close the housing.
10.Reconnect the OpenCom 130/150 to the power supply.
5.2 Configuration
The menu item S
2M
appears in the Configurator, menu PBX Configuration: Ports
after installation of the S
2M
module. Configure the port in the input mask of this
menu item. Further information on this can be found in the online help.
LED Meaning
1 (green) Synchronous (= ok)
2 (green) Blue alarm
3 (yellow) Remote alarm or out of sync
(yellow alarm)
4 (red) Loss of signal (red alarm)
