Installation Connectible Devices
55
Intercom System (for a/b)
The intercom systems “DoorLine T01/02” and “DoorLine T03/04” of the german
Telekom’s division T-Com can be connected via the “DoorLine M06” to any a/b
port. The “DoorLine” module provides the actor for the door opener contact.
Observe the following when connecting:
■ The intercom system and the “DoorLine” module should be set to their factory
settings.
■ In the PBX Configuration: Ports: a/b: Change menu in the Configurator, select
Doorstation 2-wire under Type. Activate the Actuator option, if you want to
use the actor port of the OpenCom 100 instead of the “DoorLine” relay. The
“DoorLine” actor can be operated only when the speech channel is open at the
same time. The internal actor can be operated at any time.
■ The “DoorLine” intercom system has a number of bell keys to which you can
assign different call numbers in the PBX Configuration: Ports: Doorbell menu
in the Configurator.
■ You can call the “DoorLine” intercom system by entering the code procedure
*102.
■ The “DoorLine” intercom system can be connected to any a/b port. However,
you can use only one “DoorLine” with the OpenCom 100.
For details on installing and configuring the “DoorLine” intercom system, refer to
the product user guide.
The intercom system should be installed by qualified personnel only as sensor/
actor contacts will need to be connected to the “DoorLine” module.
3.12.4 Actor/Sensor Ports
For the assignment of the ports, refer to the section Available Ports starting on
page 34. The OpenCom 100 also functions together with a Freehand Entry-Phone
manufactured by Siedle or Behnke.
