Handheld Cable/Antenna Analyzer
Chapter 2 — Instrument Overview
Introduction
This chapter describes how to get started with the E7000L SitePROFILER Cable Analyzer. Topics covered in this
section include the following:
•
Unpacking the E7000L SitePROFILER
•
Powering on the E7000L
•
Exploring the E7000L
o
Display Overview
o
Front Panel Overview
o
Test Panel Connector Overview
o
Symbols and Indicators
o
Changing date and time
o
Changing distance units
•
About the Soft Carrying Case
2-1 Unpacking the E7000L SitePROFILER
Unpack and inspect the shipping package thoroughly to ensure that nothing was damaged during the
shipment. Also check that your delivered package includes all of your ordered items in the shipment.
If contents in the package are damaged or defective, or if there are missing items, keep the shipping list
and materials for the carrier’s inspection and contact your nearest Deviser Instruments-authorized sales and
service office.
The E7000L should include the following items in the shipping package. For a comprehensive list of
compatible accessories, see Section 1-4.
2-2 Items included with E7000L shipment
Part Description Part No. Amt. Order No.
E7000L SitePROFILER Cable & Antenna System Analyzer E7000L 1 E7000L
Rechargeable Li-Ion battery pack 6130.0100.01 1 6130.0100.01
AC/DC power adapter, 11-14 VDC FSP065-RAB 1
Automotive cigarette lighter adapter E8000-0400 1
“Y” OSL Calibration Device, N(m) E7000-700 1
1.5m Test Port Extension Cable, 1.5m, N(m) to N(m), 6.0 GHz, 50Ω E7000-702 1 6190.0501.03
LAN Ethernet Cable DS8831-706 1 6190.0500.19
CD-ROM User’s Manual and Measurement Center Software E7000-0200 1 6190.0600.40
Soft Carrying Case DS2800-008 1
