Handheld Cable/Antenna Analyzer
The SiteWorkbench companion software included provides a simple and easy way to manage, archive,
and analyze current and past measurements, as well as generate and print reports. It also allows you to
customize your cable, antenna, and signal standards lists.
With its lightweight, handheld design, ease of use, and rich functionality for testing both RF coaxial and
fiber-optic feedline and antenna systems, the E7000L SitePROFILERs provides the optimal test solution to
characterize a cell site’s infrastructure.
1-2 Standard Accessories
The following components are included with your E7000L SitePROFILER:
•
Rechargeable Li-Ion Battery: 7.4V, 7.5Ah (PN: E8000-300)
•
AC/DC Adapter, 11-14 VDC (PN: FP06-DBA)
•
Vehicle Plug-in Lighter Adapter (PN: E8000-0400)
•
“Y” OSL Calibration Device (PN: E7000-700)
•
1.5m Test Port Extension Cable (PN: E7000-702)
•
CD-ROM Measurement Center Software & User’s Manual (PN: E7000-0100)
•
Soft Carrying Case (PN: E7000L-0110)
1-3 Available Product Measurement Options
Option Part Number Description Order No.
DML-015 Inline RF High Power Meter
(requires external sensor, PN E7000A-00500)
2121.8000.50
DML-E7000L-0040 Internal RF Power Meter, 20MHz – 4.4GHz 2130.7000.28
DML-E7000-OPM Optical Power Meter (includes VFL measurement option) -
DML-DI-1000 Fiber Inspection measurement mode 6250.0900.11
DML-E7000L-0030 Internal GPS module 2130.7000.30
DML-7000L-0060 Internal 802.11a/b/g Wi-Fi module 2130.7000.31
The Deviser software-enabled measurement options can be added at the time of purchase, or at a later date
as your test needs evolve – without having to return the product to Deviser Instruments or one of its authorized
service centers.
These measurement options are detailed below.
Inline RF High Power Meter (Option DML-015)
The inline RF high power meter option provides true RMS measurements with accurate measurements for both
CW and complex digitally modulated signals. It supports a 50M~6GHz frequency range. Option DML-015 does
not include the external sensor apparatus (PN: E7000A-00500) necessary for the RF Power Meter.
Internal RF Power Meter, 20MHz – 4.4GHz (Option DML-E7000L-0040)
The Internal Power Meter option provides standard-accuracy RF power testing without the need for
external equipment.
