Handheld Cable/Antenna Analyzer
Chapter 20 — Specifications
Frequency
Frequency Range 2 MHz – 4.4 GHz
Resolution 0.5 kHz
Measurement Speed
Reflection < 1.0 mS/point
DTF < 1.25 mS/point
Data Points 130, 259, 517, 1033, 2065
Measurement Accuracy
Corrected Directivity
42 dB (typical, after standard OSL calibration)
38 dB (typical, after eCAL calibration)
Output Power
0 dBm (Nominal)
Interference Immunity
On-channel
+18 dBm, >1 MHz of carrier frequency
Off-channel
+13 dBm, ±10 kHz of carrier frequency
Measurements
Return Loss 0 to 60dB (Resolution 0.01 dB)
VSWR 1:1 to 65:1
Cable Loss 0 to 30 dB (Resolution 0.01 dB)
DTF Range (Distance) 1500 meters (4921 feet)
Connectors (Reflection/RF Out)
RF Out Type N, female, 50Ω
RF Out Damage Level 25 dBm, ± 50 VDC
Connectivity
USB host USB 2.0 Type A
USB client 5-pin mini-B
(connect to PC for data transfer)
LAN RJ45 10M/100M LAN Ethernet Port
Display
Type/Size TFT LCD / 7.0” (800x480)
Data Storage
Internal 1 GB, >2000 saved measurement files
External Limited by size of USB flash drive
Battery
Type Li-Ion, 7.4V, 7.5AH
Operation TYP.> 8.0 hrs, continuous
Environmental
Operating Temperature
-10°C to +55°C
Storage Temperature -40°C to +80°C
Maximum Huminity 95% RH (non-condensing) @ 40°C
Shock Mil-PRF-28800F Class
Altitude 4600 meters, operating and non-
operating
EMC
European EMC IEC/EN 61326-1:2006
AC Power
AC Adapter Output 11-14 VDC
AC Adapter Input 100-240 VAC, 50-60 Hz
Size & Weight
Size 245mm x 190mm x 75mm
(9.64in x 7.48in x 2.95in)
Weight 2 kg (4.4 lbs)
enabled measurement options
available from Deviser, please see Section 1-3.
For a list of compatible accessories, please see
Section 1-4.
