Handheld Cable/Antenna Analyzer
2-15 Measurement Mode Selection
To perform a Cable & Antenna measurement, press the icon on the toolbar along the top of the
touchscreen display. (You can also press the Menu button to the right of the display.) This opens the E7000L
desktop function and displays the Cable & Antenna measurement mode.
Optional measurement modes can be installed on your E7000L at the time of purchase, or at a later date
as your test needs evolve. When loaded, any optional modes and associated measurement applications
will also be displayed on the desktop. Please see Section 1-3 regarding available product measurement
options.
To activate a specific measurement, simply tap the desired measurement mode icon.
SitePROFILER base model
SitePROFILER with measurement options enabled
