E7000L
SitePROFILER
Handheld Cable/Antenna Analyzer
17
Pressing
Sweep
(#3) opens the Sweep submenu, enabling you to set sweep type, points, RF immunity, RBW,
data averaging and data smoothing.
Pressing
Help
(#0) opens the Help submenu, providing context-sensitive help for main menu functions. The
Help screen displays instructions according to the measurement mode that is currently active.
Pressing
AutoScl
(.) automatically adjusts the vertical measurement scale according to the measurement
selected, e.g. return loss, VSWR, or cable loss.
Pressing
Run/Hold
(+/-) toggles the active sweep from Continuous (Run) to Single Sweep (Hold), and vice-
versa. When in single sweep (Hold) mode, the sweep will start from the start frequency (or distance on the
left of the display), sweep one time, and then stop at the stop frequency (or distance on the right hand side
of the display) and HOLD this position until activated again. When in Hold mode, the hold symbol appears
on the display.
The four
arrow keys
(around the
Enter
key) are used to scroll up, down, left, and right. The
Up/Down
arrow
keys can often be used to change a value or to change a selection from a list. This function is similar to the
function of the rotary knob. The
Left/Right
arrow keys can be used to move markers, while the
Up/Down
arrow keys can also be used to move limit lines.
LED Indicators
The Power LED is located to the right of the On/Off key. This LED is green when the unit is on.
The Charging LED is located on the test panel. This LED is red when the battery is charging, and green
when the battery is fully charged.
Sweep
Help
AutoScl
Run/Hold
