Inserting memory extensions
50 BEETLE /M-III - Service manual
18 Inserting memory extensions
Shut down the system. Remove the cable cover and pull the power plug at the rear.
Remove the housing hood.
NOTICE
Observe the instructions regarding electrostatic discharge-sensitive assemblies (see chapter "Electrostatic dis-
charge-sensitive components").
Fold the hard disk holder upwards and set it aside.
Disengage the cable on the Retail card. Neither a Retail card nor an air duct is included with a BEETLE/MIII with O1
motherboard.
Remove the cables from the holders (see arrow) of the air duct.
