Using the LPT port
70 BEETLE /M-III - Service manual
26 Using the LPT port
Shut down the system. Remove the cable cover and pull the power plug at the rear.
Remove the housing cover.
NOTICE
Observe the instructions regarding electrostatic discharge-sensitive assemblies (see chapter "Electrostatic dis-
charge-sensitive components").
Fold the hard disk holder upwards and set it aside.
Disengage the slot cover screw and remove the cover.
Insert the LPT interface into the slot that is now free.
