Important notes
6 BEETLE /M-III - Service manual
2 Important notes
The device may be repaired only by authorized qualified personnel. Improper repairs will lead to the loss
of any liability claims.
2.1 ESD
Sub-assemblies with ElectroStatic Discharge-sensitive components (ESD) can be marked with this label.
When installing sub-assemblies or modules, please observe the following information that applies to all sub-
assemblies with ESD:
– Ensure that the device is switched off and pull the power plug before you plug in, unplug or install sub-assem-
blies.
– Always use anti-static equipment (anti-static mat with ground cable with integrated leakage resistance of 1
Mohm, anti-static armband with connection to the mat, anti-statically equipped tools). The anti-static mat
must be connected to a suitable grounding point via the leakage resistance.
– Place all sub-assemblies with ESD on a suitable anti-static base.
– Touch sub-assemblies with ESD only at their edges and do not touch any components.
– Do not touch any connector pins or conductor paths on an electrostatic-discharge-sensitive assembly.
2.2 System maintenance
Clean your system at regular intervals with a dry, lint-free cloth. For greater amounts of soiling, please use a
cleaning agent suitable for plastic surfaces, as can be ordered from Diebold Nixdorf International. Make sure that
the device is deactivated during cleaning, that the power plug is disconnected and that no fluid enters the inside
of the device.
2.3 Tools required
The following took should be kept ready to hand for working on the BEETLE/ M-III:
Box spanner 5 mm (0.20")
Phillips head screwdriver PHO 1 and 2
Lateral slotted-head screwdriver 0.5 x 35 mm
Anti-static equipment
2.4 Safety precautions
The BEETLE/M-III modular system corresponds to the pertinent safety precautions pertaining to data processing
facilities.
– If this device is moved from a cold environment to its working environment, condensation may occur. The de-
vice must be absolutely dry prior to commissioning, therefore allow for an acclimatization time of at least two
hours before putting it into operation.
– The device is equipped with a safety-tested power cable. It is permitted to be connected only to a properly
grounded protective contact electrical outlet.
