Technical Information
BEETLE /M-III - Service manual 85
29.1 Interfaces (K1/K2, M1/M2 motherboard)
COM COM1 (without power supply)
COM2* - COM4* (with power supply)
Optional
COM5 - COM6 (without power supply)
COM5* - COM6* (with power supply)
USB 2 x Standard USB 2.0 at the front side
2 x Standard USB 2.0
2 x Standard USB 3.0
3 x 12 V PoweredUSB via Retail Card
1 x 24 V PoweredUSB on the power supply unit
Optional
4 x 12 V via PoweredUSB Hub not with a BEETLE/M-III with UPS, for those 3 x 12 V
PoweredUSB is standard
Graphics Adapter 1x VGA, resolution max. 1920 x 2000 Pixel @ 60 Hz
2x PLINK2/DVI-D, resolutions max. 1920 x 1200 Pixel @ 60 Hz
K1/M1: Max. 3 displays for simultaneous connection
K2/M2: Max. 2 displays for simultaneous connection
In, Out, Mic Ports for microphone, headset and loudspeaker
PS/2 1 (keyboard and mouse via Y cable)
RJ12 Cash drawer
RJ45/LAN 10/100/1000 Mbit/s
PCIe 1 x PCIe x1 and 1 x PCIe x16
LPT Optional: 1 x
Serial ATA K1/M1/M2: 3 x SATA III
K2: 2 x SATA III and 1 x SATA II
mSATA+mPCIe* K1*, K2, M1* and M2
M.2 KeyM 2280/2260; 4 x PCIe/1 x SATA to M1
