Technical Information
86 BEETLE /M-III - Service manual
29.2 Interfaces (O1 motherboard)
COM COM1 (without voltage supply)
COM2* - COM4* (with power supply)
Optional
COM5 - COM6 (without power supply)
COM5* - COM6* (with power supply)
USB 2 x Standard USB 2.0 at the front side
2 x Standard USB 3.0
2 x Standard USB 2.0
1 x 24 V PoweredUSB on the power supply unit
Optional
4 x 12 V via PoweredUSB Hub not with a BEETLE /M-III with accumulator, then 3 x
12 V PoweredUSBs are standard
Graphics Adapter 1x VGA, Resolution max. 1920 x 2000 Pixel @ 60 Hz
2x PLINK2/DVI-D, Resolution max. 1920 x 1200 Pixel @ 60 Hz
O1: Max. 3 displays for simultaneous connection
In, Out, Mic Ports for microphone, headset, loudspeaker
PS/2 1 (keyboard and mouse via Y-cable)
RJ 12 Cash Drawer
RJ45/LAN 10/100/1000 Mbit/s
PCIe 1 x PCIe x1
LPT Optional: 1 x
Serial ATA 1 x SATA III
M.2 KeyM 2280, 1 x SATA
